Antifreeze leakage into the engine is the second most common problem that owners of electric vehicles come to us with. An example is a Mercedes-Benz EQC that came to our car service.
Diagnostics showed the error «insulation breakdown on the body». This is an electric crossover with a drive on both axles, so at first, using a megohmmeter, we determined that it was the rear motor. We removed it, disassembled it, and opened the inverter. We insulated the motor windings and checked them again for breakdown. The information was confirmed - indeed, antifreeze got inside the motor, which should not have been there.
We already had a version of where the leak came from, but we decided to eliminate all doubts and check if there was a leak in the engine jacket. Moreover, traces of antifreeze were present in both the lower and upper parts of the engine. We separately pressurised all the coolant channels running through the motor and inverter - no problems were found. It turns out that antifreeze gets inside through a standard place for electric vehicles - the rotor shaft seal.
This is a serious and very common problem. Over time, or due to high engine speed, the oil seal in contact with the rotor shaft makes a depression through which coolant enters the bearing. There, it washes away the lubricant, seeps into the rotor and then into the stator. As a result, the stator winding can be damaged: it shorts out. In the most severe cases, when it is not possible to restore the resistance by washing and drying, it even has to be rewound. We can do this, too, in compliance with all factory technologies.
In addition to the rotor and stator, the electronic components of the motor can also be affected: the control board and its contacts. This is also a very big problem, because on some cars (for example, Mercedes-Benz B250 ED) there is no way to install a used board, and this greatly increases the cost of repairs. However, on other cars, it is also not easy to restore the electric motor after antifreeze has entered it.
Most often, the malfunction occurs in cars equipped with Tesla electric motors. These are the already mentioned Mercedes-Benz B250 ED, Toyota RAV 4, and sometimes Tesla itself. In these cars, the factory does not provide for emergency antifreeze drainage, which aggravates the consequences: the liquid does not go anywhere, and the engine becomes a kind of "aquarium" in which its components sink.
The problem is also inherent in other models, such as the Audi e-tron or Mercedes-Benz EQC, with which we started the story. But here, there are test plugs to check for oil seal leaks. In other cases, it is recommended to remove the motor speed sensor from time to time to check for leaks.
